Collision Proof Salt Spray Test Chamber 108L Capacity 1.8KW Max Power Easy To Clean

Collision Proof Salt Spray Test Chamber 108L Capacity 1.8KW Max Power Easy To Clean

  • Collision Proof Salt Spray Test Chamber 108L Capacity 1.8KW Max Power Easy To Clean
Collision Proof Salt Spray Test Chamber 108L Capacity 1.8KW Max Power Easy To Clean
Product Details:
Place of Origin: Guangdong, China
Certification: CE Complied
Model Number: TZ-D60
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Wooden case outside with pallet, in total 1-2CBM
Delivery Time: 5-7 working days
Payment Terms: L/C, T/T, Western Union, , MoneyGram
Supply Ability: 500 sets/ month
Contact Now
Detailed Product Description
Voltage: AC 220V Power Supply Mode: TN-S Or TT Mode
Capacity: 108L Interior Size (L*W*H) Mm: 600*450*400
External Size(L*W*H) Mm: 1100*600*1100 Weight: 100Kg
High Light:

salt spray corrosion test chamber

,

salt fog test chamber

Customized Salt Spray Test Chamber (TZ-D60)



SUMMARY

High-performance Salt Spray Corrosion Testing Equipment is ideal for testing the resistance to salt spray corrosion of some products by measuring and comparing similar materials, their usability quality.
It is applicable to test salt spray corrosion resistance of such products as parts, electronic components,
protective layer of metallic material and industrial products.


PRODUCT FEATURE

The shell of the machine is made of high quality PVC board, the structure is strong and never deformed;
Temperature controller, digital display, PID control, precise control, balanced long-term operation without drift, error ±0.1ºC;

The inner shell FRP is integrally molded, corrosion-resistant, collision-resistant, easy to clean, and no leakage; precision glass nozzle ensures no crystal blockage during operation;

Unique gas rod (no gas source), easy closing door, water-sealed structure, no salt spray overflow;
The spray tower is equipped with cone diffuser, with functions of guiding fog, adjusting fog amount and even fogging;

Double pressure high speed and over temperature protection, insufficient water level warning;
Automatic / manual water supply system, automatic / manual replenishment of water level,and the test is uninterrupted.

PROJECTS

The test is based on the following items:
1. Neutral salt spray test (NSS test, AASS acid salt spray test, CASS accelerated salt spray test)
2. Surface treatment with salt spray test

TECHNICAL PARAMETERS



Model TZ-D60
Capacity 108L
Interior Size (L*W*H) mm 600*450*400
External Size(L*W*H) mm 1100*600*1100
Weight 100Kg
Max Power 1.8KW
Max Current 10A
Power Supply Conditions and Sources

1. AC 220V two-phase + protective ground; Voltage fluctuation range 10% V;

2. Frequency fluctuate range within 50±0.5HZ; Power supply in TN-S or TT mode

3. The grounding resistance of the protective ground wire is less than 4Ω.

4. The user is required to configure the corresponding capacity of air or power switch for the equipment at the installation site. This switch must be used to independently control the device.

Installation Condition

1. Room with convection system, independent installation to prevent escaping salt spray from corroding surrounding equipment when the cover is removed.

2. The distance between the left, right and rear side panels of the test box and the wall shall not be less than 600mm, and the distance between the front and the wall shall not be less than 800mm.

Main Control Parameters

Relative Humidity: ≥85%HR

Temperature Resolution:0. 5℃

Temperature Deviation: ±1℃

Temperature Uniformity:1℃

Temperature Fluctuation:±0.5℃

Spraying(m1/80cm²/h)1.0~2.0(Collect at least 16 hours, take the average)

Spray Pressure:1.00±0.01kgf/cm²

PH Value:Neutral 6.5 to 7.2 Acidity 2.8 to 3.5

Heating Rate

Test Room Temperature:RT→+50℃≤50 min

Pressure Barrel Temperature:RT→+65℃≤35 min



PRODUCT PHOTOS

Collision Proof Salt Spray Test Chamber 108L Capacity 1.8KW Max Power Easy To Clean 0
