Corrosion Salt Spray Test Machine , Salt Spray Fog Test For Zinc Plating

Product Details:

Place of Origin:	Guangdong, China
Certification:	CE Complied
Model Number:	TZ-D60

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiation
Packaging Details:	Wooden case outside with pallet, in total 1-2CBM
Delivery Time:	5-7 working days
Payment Terms:	L/C, T/T, Western Union, , MoneyGram
Supply Ability:	500 sets/ month

Contact Now

Detailed Product Description

Type:	Salt Spray Test Machine	Power Supply Mode:	TN-S
Capacity:	108L	Interior Size (LWH) Mm:	600450400
External Size(LWH) Mm:	11006001100	Application:	Zinc Plating
High Light:	salt spray corrosion test chamber , salt spray test machine

Corrosion Salt Spray Test Machine , Salt Spray Fog Test For Zinc Plating

Salt Spray Test Machine Use

This machine has a standardized test method to check corrosion resistence of coated samples. Salt spray test is an accelerated corrosion test that produces a corrosive attack to the coated samples in order to predict its suitability in use as a protective finish. The appearance of corrosion products (oxides) is evaluated after a period of time. Test duration depends on the corrosion resistance of the coating; the more corrosion resistant the coating is, the longer the period in testing without showing signs of corrosion. Different coatings have different behaviour in salt spray test and consequently, test duration will differ from one type of coating to another.
Salt Spray Test Machine Feature
The shell of the machine is made of high quality PVC board, the structure is strong and never deformed;
Temperature controller, digital display, PID control, precise control, balanced long-term operation without drift, error ±0.1ºC;
The inner shell FRP is integrally molded, corrosion-resistant, collision-resistant, easy to clean, and no leakage; precision glass nozzle ensures no crystal blockage during operation;
Unique gas rod (no gas source), easy closing door, water-sealed structure, no salt spray overflow;
The spray tower is equipped with cone diffuser, with functions of guiding fog, adjusting fog amount and even fogging;
PROJECTS
The test is based on the following items:
1. Neutral salt spray test (NSS test, AASS acid salt spray test, CASS accelerated salt spray test)
2. Surface treatment with salt spray test
Salt Spray Test Machine TECHNICAL PARAMETERS

Model	TZ-D60
Capacity	108L
Interior Size (LWH) mm	600450400
External Size(LWH) mm	11006001100
Weight	100Kg
Max Power	1.8KW
Max Current	10A
Power Supply Conditions and Sources	1. AC 220V two-phase + protective ground; Voltage fluctuation range 10% V; 2. Frequency fluctuate range within 50±0.5HZ; Power supply in TN-S or TT mode 3. The grounding resistance of the protective ground wire is less than 4Ω. 4. The user is required to configure the corresponding capacity of air or power switch for the equipment at the installation site. This switch must be used to independently control the device.
Installation Condition	1. Room with convection system, independent installation to prevent escaping salt spray from corroding surrounding equipment when the cover is removed. 2. The distance between the left, right and rear side panels of the test box and the wall shall not be less than 600mm, and the distance between the front and the wall shall not be less than 800mm.
Main Control Parameters	Relative Humidity: ≥85%HR Temperature Resolution:0. 5℃ Temperature Deviation: ±1℃ Temperature Uniformity:1℃ Temperature Fluctuation:±0.5℃ Spraying(m1/80cm²/h)1.0～2.0(Collect at least 16 hours, take the average) Spray Pressure:1.00±0.01kgf/cm² PH Value:Neutral 6.5 to 7.2 Acidity 2.8 to 3.5 Heating Rate Test Room Temperature:RT→+50℃≤50 min Pressure Barrel Temperature:RT→+65℃≤35 min
