Humidity And Temperature Controlled Chamber , Relative Thermal Test Chamber

Humidity And Temperature Controlled Chamber , Relative Thermal Test Chamber

  • Humidity And Temperature Controlled Chamber , Relative Thermal Test Chamber
Humidity And Temperature Controlled Chamber , Relative Thermal Test Chamber
Product Details:
Place of Origin: Guangdong, China
Certification: CE Complied
Model Number: TZ-HW408
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Wooden case outside with pallet, in total 1-2CBM
Delivery Time: 5-7 working days
Payment Terms: L/C, T/T, Western Union, , MoneyGram
Supply Ability: 500 sets/ month
Contact Now
Detailed Product Description
Product Name: Humidity And Temperature Controlled Chamber Application: Temperature And Humidity Testing
Temperature Range: -40°C~+150°C Humidity Range: 20%~98%R.H
Heating Rate: 1-1.5°C/min Cooling Rate: 0.7-1°C/min
Studio Size: 600*800*850mm Volume: 408L
High Light:

constant temperature humidity chamber

,

temp humidity chamber

Humidity And Temperature Controlled Chamber , Relative Thermal Test Chamber



Humidity And Temperature Controlled Chamber Introduction



Constant Temperature Humidity Chambers can simulate the different indicators of constant temperature and humidity climate quickly and accurately for testing products which need to check their performance of temperature testing (-40℃~+150℃), humidity testing (20~98%R.H.),both of temerature and humidity testing at the same time.chamber power can be customized.

Constant Temperature Humidity Chamber which also call environment test chamber is designed for detecting the material under a variety of environmental test equipment and performance of a variety of materials holding test, cooling-off test, heating-up test, moistening test and drying test... Suitable for electronic, electrical, communications, instrumentation, vehicles, plastic products, metals, food, chemicals, building materials, medical, aerospace and other products quality testing purposes,EN 14511.



Humidity And Temperature Controlled Chamber Application:



This Chamber can simulate different environment condition. It's appropriate for testing material performance, such as resist heat, resist dry,resist humidity and resist cold. That can define performance of material.



The temperature and humidity test chamber can accurately simulate the complex natural environment of low temperature, high temperature, high humidity, low temperature and low humidity, which is suitable for the product detection of plastics, electronics, food, clothing, vehicles, metals, chemicals, building materials and other industries.



Humidity And Temperature Controlled Chamber Parameters



Model TZ-HW80 TZ-HW150 TZ-HW225 TZ-HW408 TZ-HW1000
Internal Volume(Liters) 80 150 225 408 1000
Dimension Studio size(mm) 400*400*500 500*500*600 500*600*750 600*800*850 1000*1000*1000
Machine size(mm) 900*902*1350 1005*995*1465 1050*1100*1700 1100*1350*1750 1500*1500*1950
Structure Combined structure(If the door is not wide enough, small size is available , width can be reduced by 250~300mm)
Weight(kg) Around 280 Around 280 Around 300 Around 500 Around 800
Performance Test environment conditions Test environment temperature +25°C, relative humidity≤85%, No sample in test chamber
Corresponding standard GB/T 5170.2-1996 “Method for verification of basic parameters of environmental test equipment for electric and electronic products”
Test Method

Completely stationary test mode for the object to be measured

This method is the first choice for testing, research and semiconductor screening of electronic components

Parameters Control method Balanced temperature and humidity control mode(BTHC) PID Intelligent Adjustment
Temperature range -40°C~+150°C
Humidity range 20%~98%R.H
Heating rate 1-1.5°C/min
Cooling rate 0.7-1°C/min
Uniformity Temperature: ±1.5°C Humidity: ±2.5%R.H
Fluctuation Temperature: ±0.5°C Humidity: ±2.0%R.H
Temperature Calibration point +23°C and +80°C





Package details



1. External wooden case with tray
2. The total volume is about 3-6 square
3. Suitable for export, loading and unloading
Packaging details are as follows:
